2006 |
German Championship did not happen |
|
3rd Place Team European Championship |
2005 |
German Champion |
2004 |
German Champion |
2003 |
German Champion |
|
Bronze with the FAI World Championships
(England) |
2002 |
German Champion |
2001 |
German Champion |
2000 |
German Champion |
1999 |
German Champion |
1998 |
Speed World Records |
1997 |
World Champion - First World Air Games |
1996 |
German Champion |
Records
Speed world record
500 km closed triangle
and
Speed world record
100 km closed triangle
|
|
|
|
|
- Fairings
C42 B Champion: Carbon fibre, Aramid, Glass fibre
(very lightweighted)
C42 B Competition: Glass fibre, Aramid, Carbon fibre
(lightweighted)
C42 B Club: Glass fibre
- Two-seater (side-by-side), shoulder wing, tricycle-gear
aircraft
- Landing gear, fuselage, wings, struts and tail unit
made of certified, high-strength aluminium tubing
- Fittings and screws made of stainless steel or high-strength
standard elements
- High-tech cover (UV stabilized) for wings and
empennage
- Wings easy to remove
|
- 4-cylinder-4-stroke liquid-cooled / air-cooled engine
with opposed cylinders Rotax 912 UL version, 58 kW/80
HP, including electrical starter, electronic dual
ignition, integrated reduction gearbox, carburetor
preheating or optional Rotax ULS 74 kW/100 HP
- Ground-adjustable 2-blade carbon-fibre propeller
- Spinner (Glass fibre)
- Stainless steel exhaust system
|
- All surfaces in white colour
- Cabin inside in dark grey colour
- Cabin windows and windshield Makrolon
- Elevator trim
- Hydraulic disk brakes with parking brake
- Special battery (reduced weight)
- Flight instruments:
Altimeter (10000 ft), Air speed indicator 250 km/h
with dual scale (kts) and colour indicating, Compass
- Engine instruments:
RPM indicator, oil pressure indicator, CHT gauge,
oil temperature gauge, fuel gauge
- Cabin heating
- Adjustable fresh-air inlets for windows left and
right
- Tank capacity 65 l
Many other equipment available
|
Advice - Sale -
Service - Test Flight - Spare parts
To choose the Ikarus-Flight-Centers in
your country press red button
|
|
State: 12.2003 - Technical changes reserved.
Technical informations are partially approximate values |
|
|
|
|
|
